PIPE PRODUCTION LINE

  • Glassfiber PPR Pipe Production Line|Three layers PPR Pipe Machine
    This pipe production line is used to produce 20-63mm or 20mm-110mm, 75mm-160mm, PPR glassfiber PPR pipes or 3 layer PPR pipes, with production speed up to 30m/min for 20mm×3.4mm pipe size, KAIDE is the birthplace of the first high speed pipe line in China, who can provide the stable performance and high speed line at very good price. The glassfiber ppr pipe making machine adopts high efficient extruder, three layers adjustable composite pipe die head, suffcient cooling system, stable haul-off machine,high speed pipe cutting machine, siemens PLC control system, etc
  • High Speed Two-Cavity PPR Pipe Production Line|70m/min PPR Pipe Machine
    The double strand ppr pipe production line is used to produce water supply double layers (double color) ppr pipe for hot/cold water transportation, the pipe diameter ranges are 20mm-32mm, the standard pressure ratings PN6,PN12, PN20,PN25; the produced pipes are mainly applied in the fields of building construction water supply system, air conditioner water supply system,etc. The double strand ppr pipe extrusion line speed can reach up to 35m/min*2=70m/min for 20x2.8mm. This line effectively improve the working efficiency, save human power and raw materials consumption. After do some modification, this line also can produce two layers hdpe pipe, very flexible.
  • Flat Drip Irrigation Tape Production Line| Drip Irrigation Tape Extrusion Line
    The flat drip irrigation tape production line is used to produce drip irrigation tape, with thickness 0.15mm-1.1mm, pipe diameter16mm, 20mm,22mm, this dripper sorter of this drip irrigation pipe production line can adapt various dripper type, such as AAS, DRTS, Nano etc. This drip irrigation tape line includes dripper sorter and conveying system, cross type die head moulds, high efficient extruder, vacuum tank, cooling tank, drip irrigation tape and holes punching system, automatic coiler,etc. The production line speed can reach up to 250m/min for 16x0.2mm, with driper space 300mm. This drip irrigation tape production line has exported to many countries, such as Iran, Uzbekistan, Russia, Mexico, Ukraine, Korea, etc.
  • Round Drip Irrigation Pipe Production Line|Drip Irrigation Pipe Extrusion Line
    This pipe production line is used to produce drip irrigation pipes, with round dripper inside. Production speed is 50m/min and 100m/min for 16mm drip pipe at 30cm dripper space. The drip irrigation pipe diameter range is 12mm, 16mm,20mm, the pipe thickness range is 0.5mm-1.5mm. The final manufactured drip irrigation pipe is applied in the fields of green house, fruit tree, cotton irrigation,etc. KAIDE has produce hundreds of lines for domestic and overseas customers, with rich experience to manufacture this drip irrigation pipe machine. The dripper space can be flxible adjusted from 10cm to 100cm, and the line is easy operation, controlled with intelligent Siemens PLC Control system.
  • Oxygen Barrier EVOH PERT Pipe Production Line| EVOH PE-RT Pipe Machine
    Those multilayer EVOH oxygen barrier pipe production line are used to produce 5 layer or 3 layer type PERT/EVOH oxygen barrier pipes. There are several speed models for your option, the highest speed is up to 50m/min.
    The PERT pipes with oxygen barrier are designed for underfloor heating system. They are co-extruded with 3 or 5 layers of material, giving it significant strength. For 3-layer oxygen barrier pipe structure is inner PERT, middle adhesive, and outer oxygen barrier. For 5 layer oxygen barrier pipe structure is inner PERT, adhesive, oxygen barrier layer, and outer PERT layer.
    With all advantages of PERT pipes, this floor heating pipe can effectively prevent oxygen permeating into the heating system, and thereby eliminate bacteria growth inside the pipes to ensure clean water and better sanitation, as well as protect the metal parts in the sytem from oxidization to ensure a much longer service life.
  • Micorduct Production Line|Microduct Extrusion Line| HDPE Silicone Core Duct Machine
    Weifang KAIDE plastics machinery Co.,Ltd is the first manufacturer of microduct pipe production line in China. The produced HDPE microduct silicon core pipes are widely used in Telecom industry:in the fields of outdoor communication cable, optical fibre pipeline system, public information networks, television network, expressway and railway communication projects.
    HDPE Microduct pipe machine are using 2 extruders: one for extruding HDPE layer, the other for extruding composite HDPE& silicon core layer.
    Pipe structure: 2-layer composite HDPE pipe: inner layer: HDPE , outer: HDPE silicone core. Pipe size: 5-20mm. Max. Producing speed:120m/min.
